Cambridge Audio AX-R85 – FM/AM Stereo Receiver Description & Specifications by
Times Audio
The AXR85 boasts 85 watts of power, a built-in phono stage for connecting record players with Moving Magnet cartridges, a front panel 3.5mm input for iPod/MP3 players, built-in FM/AM radio with RDS and 30 presets and four analogue inputs for connecting all your music, AV and audio sources. In addition, the built-in bluetooth receiver allows you stream your favourite music from your smartphone, tablet or PC.
SPECIFCATIONS
|
Power Output |
85 watts (into 8Ω) |
|
THD (unweighted) |
<0.01% @ 1kHz, 80% of rated power <0.15% 20Hz – 20kHz, 80% of rated power |
|
Frequency response (-1dB) |
5Hz – 50kHz |
|
S/N ratio (ref 1W) |
>82dB (unweighted) |
|
Input impedances |
47k ohms |
|
Power Amp damping factor |
>50 |
|
Standby power consumption |
<0.5W |
|
Max. power consumption |
500W |
|
Bass/Treble controls |
Shelving, ultimate boost/cut +/- 10dB @ 100Hz and 20kHz |
|
Subwoofer output |
200Hz 2nd order L+R Level follows volume setting |
|
Bluetooth |
5.0 A2DP/AVRCP supporting SBC |
|
Tuner Bands |
European AM (522-1629kHz) FM (87.5-108MHz) / US AM (530-1710kHz) FM (87.5-108MHz) |
|
Aerial Inputs |
FM 75 ohms, Coaxial. AM 300 ohms wire loop/single wire |
|
Signal to Noise (Tuner) |
60dB typical (FM) |
|
Distortion (Tuner) |
<0.4% @ 1kHz 50kHz deviation (FM mono) <0.6% @ 1kHz 50kHz deviation (FM stereo) |
|
Dimensions |
110 x 430 x 340mm (4.3 x 16.9 x 13.4”) |
|
Weight |
8.1kg (17.8lbs) |
|
In the box |
AXR85 Stereo Receiver, Power Cable, Remote Control, 2 x AAA Batteries, FM antenna, AM antenna |
